|Max. Sheet size (WxL)||1700 x 1650 mm|
|Min. Sheet Size (WxL)||420 x 380 mm|
Top paper: 150~700 gsm
Bottom paper: 300gsm ~ 8mm
|Applicable Paper||Thin paper, paperboard, coated paper, cardboard, etc|
|Corrugated Paper||G, F, E, B, C, A flute 2ply, 3ply, upto 5ply|
|Max. Working Speed||11000 sheet/hour (depends on paper quality)|
|Laminating Accuracy||±0.5mm (standard sheet paper)|
|Applicable Glue||Resin adhesive, starch glue and etc, (PH 6~8 will be suitable for laminating glue)|
|Machine Weight||9000 kg|
|Power||380V/AC/ 3P, 26kw|
Machine speed and accuracy are depended on the paper quality, operation, etc.
In the interest of product improvement, the manufacturer reservses the right to change specifications, features and configurations without notice.
